PowMr Single Phase 3000W 5000W 110V/120VAC Output Pure Sine Wave Power Inverter DC 24V 48V with 80A MPPT Solar Charge Controller
●Pure Sine Wave inverter.
● Higher output power up to 3000W /5000W
● 120Vac AC output.
● Supports single-phase devices.
● Fast switching time of 10ms.
● Compatible with 24V/48V lithium-ion and lead-acid battery, support user-define.
● Max. PV charging current up to 80A.
● Max. AC charging current up to 40A.
● Max. hybrid charging current up to 80A.
● 90~140Vac AC input voltage range.
● 120~450Vdc wide voltage range for PV access.
● 1 MPP Tracker, with 99.9% efficiency.
● Configure multiple communication interfaces (USB/CAN/RS485(WiFi/GPRS)/Dry node control).
● Durable finish with high anti-corrosion.
● Effective forced air cooling to ensure that the equipment runs stably.
|
Models
|
POW-LVM3K-24V
|
POW-LVM5K-48V
|
|
AC Mode
|
||
|
Rated input voltage
|
110/120Vac
|
|
|
Input voltage range
|
(90Vac-140Vac)
|
|
|
Frequency
|
50Hz/ 60Hz (auto-sensing)
|
50Hz/ 60Hz (auto-sensing) |
|
Overload/short-circuit protection
|
Circuit breaker
|
|
|
Efficiency
|
>95%
|
|
|
Maximum bypass overload current
|
40A
|
63A
|
|
Inverting Mode
|
||
|
Output voltage waveform
|
Pure sine wave
|
|
|
Rated output power (VA)
|
3000
|
5000
|
|
Rated output power (W)
|
3000 |
5000 |
|
Rated output voltage (Vac)
|
120Vac
|
120Vac
|
|
Maximum Efficiency
|
>92%
|
>90%
|
|
Peak power
|
6000VA
|
10000VA
|
|
Loaded motor capability
|
2HP
|
4HP
|
|
Rated battery input voltage
|
24V (Minimum starting voltage 22V)
|
48V (minimum start voltage 44V)
|
|
Power saving mode
|
Load ≤50W
|
|
|
AC Charging
|
||
|
Battery type
|
Lead acid or lithium battery
|
|
|
Maximum charge current
(can be set)
|
0-40A
|
|
|
Charge voltage range
|
20–33Vdc
|
40–60Vdc
|
|
Breaker specification
|
40A
|
63A
|
|
Solar Charging
|
||
|
Maximum PV open-circuit voltage
|
450Vdc
|
500Vdc |
|
PV operating voltage range
|
120~450Vdc
|
120-500Vdc
|
|
Battery voltage range
|
20~33Vdc
|
40-60Vdc
|
|
Maximum input power
|
4000W
|
5500W
|
|
Charge current range of solar energy
(settable)
|
0-80A
|
|
|
Authentication Specification
|
||
|
EMC authentication grade
|
EN61000
|
|
|
Noise
|
≤60dB
|
|
|
Communication interface
|
USB/RS485 (WiFi/GPRS)/dry node control
|
|
|
Dimension (L*W*D)
|
378mm*280mm*103mm
|
426mm*322mm*126mm
|
|
Weight (kg)
|
8
|
11.5
|
Hybrid Charging Max Charger Current (AC charger+PV charger): 80A
Compatible with 24V/48V lithium-ion and lead-acid battery, support user-define.
Configure multiple communication interfaces (USB/CAN/RS485(WiFi/GPRS)/Dry node control)
LCD display design to display the operation data and state of the system in real-time
Wide Range of Applications
It can be widely used in DC to AC areas, such as solar AC power system, vehicle systems, RV power supply, security monitoring systems, emergency lighting systems, household power systems, etc.
